Building Fintech Systems

That Stay Fast and Stay Compliant

Note:

Thank you for the introduction, Dominic.

My takeaway is that I am getting really old.

And I have made all the mistakes one can do in this business at least twice.

I have built systems that moved lots of data and money, and most of the time they stayed up.

But: The times that they fell over taught me more.

At Klarna, we moved fast, sometimes faster than the BEAM had ever been pushed before.

We had one-gigabyte processes, two terabytes of RAM, and once hit the limit of 4,096 catch frames. We did not have problems with compliance, but we did hav some technical challenges as we explored new territory.

In 2005 we did not have GDPR yet and the compliance regulations for a payment provider in Sweden were pretty simple.

As we grew and new regulations entered we could easily adept.

The thing was, we already had a lot of what regulators ask for, logging, traceability, and strict ‘break-the-glass’ access, not because someone told us to, but because thats good engineering.

Those same practices are what helped us find and fix the problems at 2 AM. Years later I realized: compliance is just good engineering done on purpose. And when you do that, speed follows.

Compliance Myths

Slows you down
Belongs to lawyers
Means paperwork

What does good engineering done on purpose look like?

Pattern 1: Isolation Boundaries

Thinking in Processes

To help you think about process-oriented programming, let’s introduce three ideas:

Domains: code & data boundaries
Process Archetypes: common behavioral patterns
Flows: how data and messages move

Pattern 1: Isolation Boundaries as Domains

Domains define what belongs together.

Pattern 1: Isolation Boundaries as Archetypes

Different view: roles at runtime.

Pattern 1: Isolation Boundaries as Flows

Four kinds of flow: data, message, process, call.

From Boundaries to Movement

Isolation boundaries give structure.

Now let’s look at movement inside those boundaries, how change travels safely through the system.

Pattern 2: Idempotent Change Flow

Message example

Msg = #{
  trace_id => T,
  actor    => <<"3f7e8c4-9d2b-4a15-8e6f-1c5b3d4a7f9e">>,
  op       => <<"authorize">>,
  amount   => 14999, ccy => <<"SEK">>, scale => 2,
  meta     =>  #{psp => <<"AcmePay">>,
                 idempotency_key    => T }
}.

Ledger-side dedup idea (conceptual)

Maintain a dedup ETS table: dedup: seen(T) -> true | false.

On post:

if seen(T) -> {ok, already_applied, Prev_result};
   true -> append(E),
           mark_seen(T),
           {ok, new, Result}
end

PSP-side idempotency (conceptual)

Outbound: include Idempotency-Key: T (or body field) so PSP won’t double-charge on retries.
Inbound: if PSP sends webhooks multiple times → dedup by (psp_event_id || T).

You Build It · You Own It · You Run It

Ownership is compliance.

With Ownership Comes Trust

Give developers the tools and the trust to act responsibly.

“Break-the-glass” access for real incidents
Clear audit trail of every action
Fair compensation and proper on-call terms

The One Rule That Works

Every change must have a reason.

One ticket → one branch → one deploy.
Branch name = ticket_nr + documentation.
Commit message explains what.
The ticket explains why.

Never Use Floats (for Money)

❌ "149.99" (string)
❌ 149.99 (float)
✅ {amount: 14999, currency: "SEK", scale: 2}

Where This Maps to Regulations

Regulation	What it asks for	Engineering pattern
PSD2 / NIS2	Isolation of risk & failover	Isolation Boundaries, Circuit Breakers
GDPR	Data minimization, traceability, forget-me	Typed data, trace_id + PII mapping, "break-the-glass" access
PCI DSS	Segregation of duties, controlled data flow	Ledger Domain, Gatekeepers, supervised processes
SOC 2 / ISO 27001	Change management & auditability	Ticket → branch → deploy, Idempotent Change Flow
AML / KYC	Transaction traceability	Ledger events with actor + trace context

Lessons learnt (the hard way)

Isolation Boundaries → Contain Risk
Idempotent Change → Safe Movement
YBYOYR → Lasting Culture

One System. Both Fast and Compliant.

Thank You

If we have time:

Press → for Mini-Ledger demo
Press → again for Process Archetypes

Otherwise:

Press → twice to skip to Next Steps

Erlang Mini-Ledger

Append-only ledger with a hash chain + Merkle root over balances.
Show: immutable history, crash safety, proof-of-state.

Observer

observer:start().

The Code: ledger.erl (Core)

post(Account, Delta, Currency) ->
    Ts = erlang:system_time(millisecond),
    Entry = #{ts => Ts, acct => Account,
              delta => Delta, ccy => Currency},
    Prev = prev_hash(),
    TxHash = sha256(term_to_binary(Entry)),
    BlockHash = sha256(<<Prev/binary, TxHash/binary>>),

    ets:insert(?CHAIN, {Ts, Entry, TxHash, Prev, BlockHash}),
    update_balance(Account, Delta, Currency),
    ets:insert(?META, {?PREV, BlockHash}),
    {ok, BlockHash}.

The Code: Merkle Root

state_root() ->
    Leafs = lists:map(
        fun({A,B,C}) ->
            sha256(<<(term_to_binary(A))/binary,
                     (term_to_binary(B))/binary,
                     C/binary>>)
        end,
        lists:sort(ets:tab2list(?BAL))),
    merkle:root(Leafs).

Compact commitment to all balances. Any change produces a different root.

Step 1 — Start the Ledger

1> c(ledger_store), c(ledger), c(merkle), ledger:start().
ok

ETS-backed append-only chain
Hash = SHA256(prev_hash || txn)
Balances updated from entries
ledger_store owns the ETS tables (heir pattern)

Step 2 — Post Transactions

2> ledger:post(user_1, 14999, <<"SEK">>).
{ok,<<...>>}
3> ledger:post(user_1, -2500, <<"SEK">>).
{ok,<<...>>}
4> ledger:balance(user_1).
12499

Entries are appended; nothing is overwritten.

Step 3 — Prove State (Merkle Root)

5> ledger:state_root().
<<RootHash:256/bits>>
6> ledger:balances().
[{user_1,12499,<<"SEK">>}]

state_root() is the Merkle root over the sorted balance set.
Any stakeholder can recompute and match.

Step 4 — Fault Containment (Heir Pattern)

7> whereis(ledger_worker).
<0.123.0>
8> exit(whereis(ledger_worker), kill).
true
9> ledger:balance(user_1).
12499  % Still works! Tables transferred to heir
10> ledger:start_worker().
{ok, <0.125.0>}
11> ledger:balance(user_1).
12499  % Data intact after worker restart

Worker dies → tables transfer to ledger_store (heir).

What Are Merkle Proofs?

Problem: Your auditor needs to verify one account balance without accessing your entire database.

Solution: Merkle tree, a cryptographic commitment to all balances.

Each balance becomes a leaf hash
Pairs combine into parent hashes
Final root commits to entire state

Merkle Tree Structure

           Root (6A93...)
              /     \
         H_AB         H_CD
         /  \         /  \
      H_A  H_B     H_C  H_D
       |    |       |    |
    user_1 user_2 user_3 user_4
    12499  4000   8500   2100

To prove user_2 balance:

Show leaf H_B (hash of user_2, 4000, SEK)
Show path: [H_A (left), H_CD (right)]
Anyone can recompute: hash(hash(H_A, H_B), H_CD) = Root

Why This Matters for Fintech

Privacy: Prove one balance without revealing others
Compact: Log N proof size (8 hashes for 256 accounts)
Verifiable: Anyone can check against published root
Historical: Generate proofs for any past state

This is what makes blockchains auditable.

You don't need a blockchain: plain Merkle trees in Erlang work fine.

How Verification Works

You publish: Root hash 6A93...

User claims: "I have 4000 SEK"

User provides proof:

Leaf: hash(user_2, 4000, SEK) = 8C75...
Path: [H_A (left sibling), H_CD (right sibling)]

Verifier computes:

Step 1: hash(H_A, 8C75...) = H_AB
Step 2: hash(H_AB, H_CD) = 6A93...
Check: Does this match published root? Yes → Valid

Live Demo: Merkle Proofs

12> c(proof_pp).
{ok, proof_pp}
13> {ok, H1} = ledger:post(user_2, 5000, <<"SEK">>).
{ok, <<H1:256/bits>>}
14> {ok, H2} = ledger:post(user_2, -1000, <<"SEK">>).
{ok, <<H2:256/bits>>}
15> {ok, P} = ledger:proof(user_2).
{ok, #{balance => 4000, ...}}

Understanding the Proof Structure

16> proof_pp:show(P).

=== Proof of Balance ===
Account : user_2
Balance : 4000 "SEK"
Leaf (account hash):
  8C75A23F...4E9FAE12
Path (2 siblings):
  -> left 91AB4C2D...8F331D0A
  -> right 0F88E7B1...3A7CC491
Root :
  6A9312B7...9C4F8E2D

Verify the Proof

17> merkle_proof:verify(user_2, 4000, <<"SEK">>, maps:get(proof, P)).
true

Historical Proof (Rewind to H1)

18> {ok, P1} = ledger:proof_at(user_2, H1).
{ok, #{balance => 5000, at_block => H1, ...}}
19> proof_pp:show(P1).

=== Proof of Balance ===
Account : user_2
Balance : 5000 "SEK"
At block: 3A7F8E12...9C2B4D76
Leaf (account hash):
  2F4C9A81...6D7E3B92
Path (1 siblings):
  -> right 8B3E2C1F...4A9D7F05
Root :
  D4F8A2E6...7B1C9E34

20> merkle_proof:verify(user_2, 5000, <<"SEK">>, maps:get(proof, P1)).
true

From Reliability to Verifiable State

Ledgers: every change append-only, reconstructable
CRDTs: concurrent updates that converge without locks
Patricia-Merkle Trees: cryptographic proof of balances and state

Process Archetypes

Worker Handles one task. Dies after. You can pool them if needed.

Resource owner Keeps state. A cart, a session, a WebSocket.

Router Receives, decides, forwards. Never stores.

Gatekeeper Limits something. One message at a time, access to a resource.

Observer Watches processes, reacts to conditions.

Worker: Short-lived workers

Spawn, do one job, exit. Use these for things like sending emails, updating logs, writing audit trails.

Worker: Pooled workers

Lives in a pool when not running, does one job, returns to pool. Can keep some state, like configuration.

Router: Broadcaster

Fan out of messages.

Router: Director

Route messages to the right receiver.

Gatekeeper: Flow controllers

Processes that gate, synchronize, or sequence other flows.

They manage contention, enforce ordering, or regulate access.

Gatekeeper: Rate limiters

Provides back pressure.

Gatekeeper: Circuit breakers

When subsystems stall or crash, they keep the damage local.

Resource owner: Entity owner

Processes that wrap state.

A payment intent. A socket. A user.

Can be implemented with a gen_server.

Resource owner: Aggregator

Collector, windowing, rollups.

Observer: Sentinel

Watchdogs, deadlines, cancellations.

Observer: Supervisor

Watches others. Restarts them. Never does real work.

They know who to restart and when to walk away.

Next Steps

Fintech

Feedback

happihacking.com/blog/
Fintech BEAM checklist → happihacking.com/fintech/
Upcoming books: Building Scalable Fintech Systems, Erlang by Doing ?
